Documo eFax + Salesforce Integration, A Complete Setup Guide

Fax machines were supposed to disappear a decade ago. Instead, healthcare providers, law firms, insurers, and government agencies still depend on eFax daily because it remains a legally recognised, compliance-friendly way to exchange documents. The catch is that fax has always lived in its own bubble, arriving in a separate portal, creating no CRM record, and forcing agents to bridge two systems by hand.

Documo removes that bubble. As a cloud-native eFax platform with a full REST API and real-time webhook delivery, it can integrate directly with Salesforce, the world’s leading CRM. This blog covers a complete, production-grade, bidirectional integration, spanning inbound faxes that create Salesforce Cases automatically and outbound faxes sent from a Lightning Web Component. Here is how the full stack fits together.

Why This Integration Matters Now

Digitizing communication channels inside the CRM is no longer optional; it is the baseline expectation. A global survey by Harvard Business Review Analytic Services found that 94% of respondents say that digitizing workflows is important to their organization, and organizations doing this well reported gains in efficiency, streamlined processes, better tool access, and improved collaboration.

An eFax number is one of the last paper-adjacent channels still running outside the CRM. Every fax that lands in a standalone portal instead of a Case record is a small workflow gap, and gaps like this compound across a support team. Connecting Documo to Salesforce closes that gap directly, turning a legacy compliance channel into a fully tracked, automated part of the CRM.

Architecture at a Glance

The integration runs both ways. An inbound fax triggers a Documo webhook that calls a Salesforce Apex REST endpoint, creating a Case and attaching the document automatically. An outbound fax originates from a Lightning Web Component, calling an Apex controller that invokes the Documo REST API through a Named Credential.

Step 1: Documo Platform Setup

Provision a toll-free eFax number. Log into the Documo portal and go to Numbers → Add Number, select Toll-Free, choose a country, and complete provisioning. This number becomes the single inbound channel for all fax communication. Note its unique identifier for use in Custom Metadata later.

Generate a Documo API key. Go to Settings → API Keys → Create API Key and copy it immediately, since it is shown only once. This key authenticates every outbound callout from Salesforce to Documo and should live inside a Salesforce External Credential, never in Apex source code.

Configure the inbound webhook. Under Webhooks → Create Webhook, set the event type to fax.received and point the URL at your Salesforce Apex REST endpoint. Generate a strong random secret for this webhook. Documo signs every payload using HMAC-SHA256 with that secret and sends the resulting signature in a request header, which the Apex endpoint validates on every call before processing anything. Store this secret in Custom Metadata.

Step 2: Salesforce Connected App, Client Credentials Flow

The OAuth 2.0 Client Credentials Flow is the right mechanism for machine-to-machine integration with no user interaction. Documo posts its credentials directly to the Salesforce token endpoint, receives a Bearer access token, and includes that token in the Authorization header of every webhook call. No certificates, redirect URIs, or authorization codes are involved.

Create the Connected App. Under Setup → App Manager → New Connected App, enable OAuth Settings, add the API and offline access scopes, and enable the Client Credentials Flow. Retrieve the Consumer Key and Consumer Secret from Manage Consumer Details afterward.

Assign a run-as user and set IP Relaxation. Under Manage → Edit Policies, set Run As to a dedicated integration user with API access, create permissions on Case, ContentVersion, and ContentDocumentLink, and Apex class access for the handler and controller. Set IP Relaxation to Relax IP restrictions, since Documo’s token requests come from cloud infrastructure without fixed IPs.

Hand over credentials. Give Documo’s webhook configuration the Salesforce token endpoint URL, Consumer Key, Consumer Secret, and grant type. These values should never touch code or version control.

Step 3: External Credential and Named Credential

Named Credentials manage outbound callout authentication correctly, since secrets stay encrypted and resolve at runtime rather than being hardcoded.

Build the External Credential. Under Setup → Named Credentials → External Credentials → New, set the Authentication Protocol to Custom, create a principal, and add the Documo API key with the Bearer prefix as an authentication parameter. Grant External Credential Principal Access through a permission set assigned to the run-as user and anyone sending outbound faxes.

Create the Named Credential and Remote Site Setting. Point the Named Credential at the Documo REST API base URL, link it to the External Credential, and enable formula support in headers and body. In Apex, the key is injected at callout time through a merge field and never appears in source code. Finally, add the Documo API domain as an active Remote Site under Setup → Remote Site Settings.

Step 4: Custom Metadata Type

Custom Metadata Types are the correct mechanism for deployable, version-controlled configuration, since they move through change sets and unlocked packages without the governor limit concerns of Custom Settings. Create a type such as Documo_Config under Setup → Custom Metadata Types → New, with an encrypted text field for the Webhook Secret, a text field for the Account UID, and a text field for the Default Fax Number. Populate one default record with all three values. This record gets queried at runtime by the configuration provider class.

Step 5: Apex Implementation

The Apex layer is structured as nine classes with clear separation of concerns: an exception type, wrappers for the webhook payload and outbound fax request/response, a configuration provider that reads and caches Custom Metadata, a service class handling HTTP callouts through the Named Credential, a processor that creates the Case and attaches the file, a @RestResource webhook handler, and an @AuraEnabled outbound controller.

Key security patterns. HMAC signature validation runs first in the webhook handler, so any request with a missing or mismatched signature is rejected with HTTP 422 before any DML or callout executes. Named Credential merge fields handle every Authorization header, so the API key never appears as a string literal. Input validation is layered across the LWC, the request wrapper, and the controller’s regex check, and with sharing on the outbound controller stops agents from sending faxes off records they cannot access.

Step 6: Lightning Web Component

The documoOutboundFax LWC deploys to Record Pages and App Pages. It offers a recipient fax number input with client-side regex validation, a read-only sender number populated via a wire call, an optional cover note, a PDF-only file input capped at 10 MB, and Send and Clear buttons with loading states and toast notifications. The component reads the file as Base64 through the FileReader API and validates everything client-side before any server call fires.

Step 7: Deployment Checklist

Documo and Salesforce

• Toll-free number provisioned
• API key stored in an External Credential
• Webhook created for fax received with the HMAC secret in Custom Metadata
• Remote Site Setting active
• Named Credential linked
• Permission set assigned to the run-as user

Connected App, Apex, and LWC

• Client Credentials Flow enabled with a dedicated run-as user
• All nine Apex classes deployed with the REST endpoint path matching Documo’s webhook URL exactly
• The documoOutboundFax component added to the target record page

End-to-End Validation

• Send a test fax and confirm a Case appears within seconds with the PDF attached
• Open the LWC, send a test fax, and confirm the success message and fax ID display correctly

Security Summary

Client Credentials Flow handles authentication between Documo and Salesforce without certificates or interactive login. HMAC-SHA256 validation adds a second, independent layer of trust on the inbound webhook. Named Credentials keep the Documo API key encrypted and out of source code or logs, with rotation requiring only a single field update, while with sharing on the outbound controller enforces record-level security throughout.

Ksolves: Bringing This Kind of Integration to Your Salesforce Org

Projects like this rarely stop at connecting two APIs. They involve OAuth design, secret management, deployable configuration, and a UI layer that agents actually enjoy using. This is exactly the kind of work our Salesforce Consulting Services team handles for clients who want their CRM to absorb legacy channels instead of working around them.

Ksolves is a top-notch Salesforce Partner and an AI-first company, so integrations like this are built with automation and intelligent workflow design from the ground up. Whether it is eFax, a legacy document system, or a custom AI layer inside Salesforce, our team scopes, builds, and deploys it with the same rigor shown here. Engagements like this typically run through our Salesforce Professional Services team, who scope the Apex, security, and UI layers together.

Conclusion

Connecting Documo eFax to Salesforce turns a channel that has always sat outside the CRM into a fully automated, auditable part of it. Every inbound fax becomes a Case with the document attached in seconds. Every outbound fax goes out in a few clicks, with no portal switching and no secrets sitting in code.
