NiFi Connectors: Turning Complex Dataflows into a Simple Wizard

Apache NiFi has always been a powerful tool for building dataflows. That power, however, comes with a learning curve. Standing up even a “standard” pipeline — say, moving data from Kafka into object storage — means dragging processors onto the canvas, wiring them together, configuring controller services, and tuning dozens of properties correctly.

NiFi’s newer Connectors feature is designed to remove that barrier. This post explains what Connectors are, how they work, and walks through the first reference implementation — the Kafka-to-S3 connector — using details taken directly from the NiFi 2.10.0 source and the documentation shipped with the connector.

What is a Connector?

A Connector is a pre-built, wizard-configured data pipeline that manages its own Process Group internally. Instead of assembling processors by hand, a user fills in a short, guided configuration wizard, and NiFi builds and maintains the underlying flow automatically.

The key distinction: a Connector is not a processor. It is a higher-level abstraction that sits above the canvas. Behind the scenes it still produces an ordinary NiFi flow made of real processors and controller services — but the user configuring it never has to see or touch that complexity unless they want to.

Connectors first appeared as an initial framework capability, and NiFi 2.10.0 added the user-facing UI that makes them usable end to end. Apache NiFi’s release notes record the initial Connectors support landing in the 2.9.0 release, dated April 10, 2026, with the interface work following in 2.10.0.

Teams still on an older release should know how to validate a NiFi version upgrade before jumping to 2.10.0 purely to unlock Connectors.

How Connectors Work

Every Connector is built around two ideas: configuration steps and a managed flow.

Configuration steps define the wizard. Rather than presenting a flat list of forty properties, a Connector groups related settings into ordered steps, each with its own documentation. The user moves through the steps one at a time, and each step can be individually verified against the target system before moving on.

The managed flow is the actual NiFi flow the Connector builds from the user’s answers. The Connector owns a Process Group and keeps it in sync with the configuration:

1. When the wizard is first completed, the Connector loads an initial flow template and applies the user’s values to it.
2. When a step is reconfigured, the Connector rebuilds the flow to match — and, importantly, it does this safely.
3. If a change is potentially disruptive (for example, changing the output data format), the Connector first drains in-flight data from the existing flow before rebuilding it, so nothing is lost or corrupted mid-change.

A Closer Look: The Kafka-to-S3 Connector

Kafka-to-S3 is the first connector shipped with NiFi and serves as the reference implementation. Its own description sums up the job cleanly: it ingests data from Apache Kafka topics, merges it into objects of a reasonable size, and writes that data to Amazon S3.

In NiFi 2.10.0, Connectors get their own top-level entry in the main menu. Opening it shows the Connectors listing page, where each connector appears with its name, type, backing bundle, and state. The Kafka-to-S3 connector (type KafkaToS3 2.10.0, bundle org.apache.nifi – nifi-kafka-to-s3-nar) is listed here, with Connectors available as a dedicated menu item.

Getting the consumer group ID and offset-reset behavior wrong here is one of Kafka’s real-world implementation challenges that trips up teams building this pipeline by hand.

Under the hood, the managed flow it builds is straightforward and familiar to any NiFi user:

ConsumeKafka → MergeRecord → PutS3Object

supported by a Kafka connection controller service and an AWS credentials controller service. That is exactly the flow an experienced developer would build by hand — the Connector just assembles and maintains it for you.

The configuration wizard has three steps.

Step 1 — Kafka Connection

This step captures how to reach the Kafka cluster: the bootstrap servers (one or more brokers as a comma-separated list) and the security protocol. The supported protocols cover the common cases — PLAINTEXT, SSL, SASL_PLAINTEXT, and SASL_SSL (the last being the recommended option for both authentication and encryption). If SASL is used, the step collects the username and password. It also allows an optional Schema Registry URL for topics that use Avro, Protobuf, or JSON Schema.

Step 2 — Kafka Topics

Here the user selects which topics to consume — and the connector fetches the available topic list from the cluster automatically. This step also sets the consumer group ID (used by Kafka to track offsets and guarantee each message is processed once within a group), the offset-reset behavior (earliest, latest, or none), and the incoming data format (Avro or JSON).

Step 3 — S3 Configuration

The final step defines the destination and how data is batched. It covers the S3 bucket, an optional key prefix, the AWS region, and the output data format (JSON or Avro). It also exposes the merge settings — a target object size and a merge latency — which control how many Kafka messages are combined into a single S3 object and how long the connector waits before flushing, balancing object size against data freshness. Credentials can be supplied explicitly (access key and secret) or via the default AWS credential chain (environment variables, IAM roles, and so on), and an endpoint-override field allows the same connector to target S3-compatible systems such as MinIO or LocalStack.

Built-In Verification and a Troubleshooting Mode

Two features make Connectors practical for real use rather than just convenient.

Per-step verification lets the user validate a step before committing — for example, checking Kafka connectivity or confirming the selected topics exist — so misconfiguration is caught early instead of after the flow is running.

Troubleshooting mode acknowledges that abstractions sometimes need to be opened up. It lets a user look inside the Connector’s managed Process Group to inspect the real flow when something is not behaving as expected. When the user exits troubleshooting mode, the Connector reinstates its authoritative flow, discarding any manual edits — so the managed flow always returns to a known, connector-defined state.

Why This Matters

The Connector model changes who can build integrations in NiFi. Previously, standing up a common pipeline required NiFi expertise. With Connectors, an expert builds the integration once — as a reusable connector — and everyone else consumes it through a short wizard. The heavy lifting (processor wiring, controller services, safe reconfiguration, data draining) moves into the framework.

For teams running NiFi at scale, this is a meaningful shift: fewer bespoke flows to maintain, more consistency across pipelines, and a much lower barrier for non-specialists to get productive.

If you’re unsure whether Connectors fit your existing setup, Ksolves’ NiFi development team can review your current NiFi footprint and flag where a wizard-driven connector would save the most rework.

Trying It Out and What’s Next

Kafka-to-S3 is the reference connector today, and it is a clear template for what future connectors will look like. Custom connectors can be written by extending the connector base class and defining their own configuration steps and managed flow, which means organizations can package their own recurring pipelines as first-class, wizard-driven connectors.

As of NiFi 2.10.0 the Connectors UI is available, with more connectors expected in subsequent releases. If you already run NiFi 2.10.0, the Kafka-to-S3 connector is the best place to see the model in action end to end.
